Egg washing, grading, and packaging system JOB series
A professional egg cleaning, grading, and packaging system that has sold over 400 units and has had a profound impact on the world.
Safe and accurate, efficient and simple. The world leading computer centralized control fully automatic egg cleaning, grading and packaging system. The JOB series, which keeps up with the times, is also the most representative standard egg cleaning and grading packaging system among global machines.
Keeping the original simple and superior basic design, the graded packaging control system adopts the same CPU as the latest model, which greatly improves its operational performance. The evolution of various packaging mechanisms that can handle packaging containers with ease has achieved a variety of packaging forms. Also, the low height and good visibility of the framework structure facilitate smooth communication among the staff.
25000~30000 pieces/hour (single 6 columns)
50000 to 60000 pieces per hour (6 columns of double or 12 columns)
90000 pieces per hour (double combination of 6 and 12 columns)
Details
Cleaning and drying devices to improve yield
This sanitary egg washing and drying machine features a stainless steel frame with all electrical components installed on the upper part of the unit. It can be used together with the separately sold foam cleaning device to maintain superior hygiene. It adopts one-touch or sliding cover plates for easy inspection and cleaning. All brushes are equipped in standard specifications: 10 washing brushes for egg cleaning, 10 top drying brushes and 8 bottom drying brushes. The JOB series delivers excellent washing and drying performance.
Stronger operability
The upgraded computer control system greatly improves the machine's operability and computing speed. It optimizes the presetting of egg carton quantities and enhances the recalculation function after egg grading. In addition, it supports invoice data storage, enabling reissuance of previous invoices.
Flexibly respond to the diversity of packaging containers
The machine distributes weighed eggs to different packaging lines by weight and packs them into designated containers. It combines various packaging mechanisms and container feeding devices to adapt to diverse packaging container types.
Satisfy customer needs
The optional configuration includes a cleaning device compatible with graders. It uses brushes to effectively remove dirt on the sides of machine conveying claws and reduce cleaning workload. This conveying claw cleaning device can also be installed on existing machines as required by customers.
Accuracy and Trust
This high-precision weighing equipment resists vibration and foreign matter interference. It keeps the error within ±1% after automatic calibration. Equipped with durable weighing sensors, it ensures long-term continuous stable operation of the machine.
Standard floor plan
| Processing Speed | 30000 eggs/hour |
| Voltage | Three-phase 380V 24.5kW / Single-phase 220V 3.5kW (JOB-300) |
| Hot Water Consumption | 8L/min (55~60℃) |
| Water Consumption | - |
| High Pressure Air Consumption | 80NL/min (0.6~0.9MPa) (JOB-300) |
| Processing Speed | 60000 eggs/hour |
| Voltage | Three-phase 380V 24.5kW / Single-phase 220V 3.5kW (JOB-300) |
| Hot Water Consumption | 15L/min (55~60℃) |
| Water Consumption | - |
| High Pressure Air Consumption | 80NL/min (0.6~0.9MPa) (JOB-300) |
| Processing Speed | 90000 eggs/hour |
| Voltage | Three-phase 380V 24.5kW / Single-phase 220V 3.5kW (JOB-300) |
| Hot Water Consumption | 23L/min (55~60℃) |
| Water Consumption | - |
| High Pressure Air Consumption | 80NL/min (0.6~0.9MPa) (JOB-300) |
